Digital manometer MANO200

Digital manometer MANO200

The MANO200 digital pressure gauge is a portable device allowing precise measurement of positive and negative differential pressures, as well as air flow and temperature. It is equipped with a liquid crystal display and manual zero point compensation (auto-zero). Its size and ease of use make it ideal for maintenance work on heating, air conditioning or ventilation units, where it allows monitoring of filters and measurement of chimney drafts and flow rates.


Product reference : MANO200 selon FP2854
Availability : 2 or 3 weeks
Technical sheets
Consult

Detailed description
PARAMETERS VALUES
Measurement uncertainty 0.5 % of the final value
Overload capacity 10 times for measuring ranges ≤ 10 kPa

2 times for measuring ranges > 10 kPa

1.2 times for measuring range 200 kPa

Calculation of air speed v = 1.291 x √∆P

ith v in m / s and ∆P = different pressure on the Pitot tube in Pa

(Pitot factor and adjustable density)

Zero point compensation (Auto-zero) Manually using the auto-zero key
Fluids Air, all non-aggressive gases
Analog output 0 … 2 V (RL ≥ 2 kΩ)

0 … 1 … 2 V (RL ≥ 2 kΩ)

For negative and positive measuring ranges

Display LCD display, 3.5 digits (digit height 13 mm)
Time constant 1 … 10 s
Operating temperature 0 … 50 °C
Storage temperature -10 … 70 °C
Recommended position of use Horizontally
Power supply 9 V battery (approx. 100h lifespan)
Weight 0.4 kg
Pressure fittings For pipe DN 4 or 6 mm
Certifications CE
